CW-1500 Water Chiller
CWFL-1500 fibre laser chiller, designed for 1500W fibre laser cooling, dual-temperature dual-control mode, separate low temperature and high temperature, able to cool the laser and laser head at the same time, a multi-purpose. With constant temperature and intelligent temperature control mode; intelligent temperature control mode, the water temperature changes with the room temperature (2 degrees lower than the room temperature), effectively avoiding the generation of condensate; top fan, effectively improve the chiller’s own heat dissipation.
Product Features
1. Cooling capacity up to 430W, using environmentally friendly refrigerant
2. Stable cooling, compact size, easy to operate
3. Temperature control accuracy up to ±0.5°C
4. Laser chiller intelligent temperature controller with two temperature control modes, suitable for different use occasions; a variety of settings and fault display function。
5. With a variety of alarm protection functions: compressor delay protection; compressor overcurrent protection; water flow alarm; temperature over/under the alarm
6. Multi-country power supply specifications; ISO9001 certified, CE certified, RoHS certified, REACH certified
7. Optional heater and water purification configurations available.
Product Parameter
| Model | CWFL-1500ANS03 | CWFL-1500BNS03 |
| Voltage | AC 1P 220~240V | |
| Frequency | 50Hz | 60Hz |
| Current | 1.2~12.3A | 1.2~11.9A |
| Max. power consumption | 2.13kW | 2.45kW |
| Heater power | 400W+600W | |
| Precision | ±0.5℃ | |
| Reducer | 毛细管Capillary | |
| Pump power | 0.26kW | |
| Tank capacity | 12L | |
| Inlet and outlet | Rp1/2″+Rp1/2″ | |
| Max. pump pressure | 30M | |
| Rated flow | 1.5 L/min + >12L/min | |
| G.W. | 51Kg | |
| Dimension | 59 X 38 X 74cm (L X W X H) | |
| Package dimension | 66 X 48 X 92cm (L X W X H) | |
