CW-6000 CO₂ Laser Chiller
The CW-6000 is excellent for cooling 300W CO₂ DC laser tubes and 100W sealed CO₂ lasers. With the characteristics of high flow rate and high head, the use of this chiller can effectively improve the working efficiency of CO2 laser equipment, while reducing the cost of use for users.
Products Categories
Get A Free Quote
Product Features
- Cooling capacity up to 2400W, using environmentally friendly refrigerant.
- Stable cooling, compact size, easy to operate.
- Temperature control accuracy up to ±0.3°C.
- Laser chiller intelligent temperature controller with two temperature control modes, suitable for different use occasions; a variety of settings and fault display function.
- With a variety of alarm protection functions: compressor delay protection; compressor overcurrent protection; water flow alarm; temperature over/under the alarm.
- Multi-country power supply specifications; ISO9001 certified, CE certified, RoHS certified, REACH certified.
Chiller Parameter List
| Model | CW-6000AH | CW-6000DH |
| Voltage | AC 1P 220~240V | AC 1P 110V |
| Frequency | 50/60Hz | 60HZ |
| Current | 0.5~5.2A | 0.5~8.9A |
| Max. power consumption | 1.04/1.4kW | 0.96/1.51kW |
| Compressor power | 0.88/0.94kW 1.18/1.26HP | 0.79kW 1.06HP |
| Nominal cooling capacity | 10713Btu/h 3.14kW 2699Kcal/h | |
| Refrigerant | R-410A | |
| Precision | ±0.5℃ | |
| Reducer | Capillary | |
| Pump power | 0.05/0.09/0.37/0.6KW | |
| Tank capacity | 12L | |
| Inlet and outlet | 10mm Barbed connector | |
| Max. pump pressure | 12/25/27/40M | |
| Max. pump flow | 13/15L/75L/min | |
| N.W | 43KG | |
| G.W | 52KG | |
| Dimension | 590*380*740mm (L X W X H) | |
| Package dimension | 660*480*920mm (L X W X H) | |
