QCW 300W, 450W Laser Sources
QCW 300/450W fibre laser has a compact structure and simple design style, which can be directly integrated into the user’s equipment. Low power consumption and practical, stable energy, simple and convenient installation, is the perfect alternative to YAG welding host products, widely used in medical, mobile phones, flat panel products such as precision welding and cutting!
Products Categories
Get A Free Quote
Product Features
1. Wide range of applications: mainly used for precision welding and precision cutting, such as computers, mobile phone parts processing, power battery copper and aluminium material welding, ceramic cutting, drilling, marking and other processes。
2. Continuous and pulsed modes
3. Extremely stable output performance
4. Excellent beam quality
Laser source parameters
| model number | QCW-300W | QCW-450W | ||
| centre wavelength （nm） | 1080±10 | |||
| operating mode | Continuous/Pulse | |||
| modulation frequency （KHZ） | 10 | |||
| Continuous Mode Maximum Power (W) | 300 | 450 | ||
| Maximum peak power in pulse mode (W) | 3000 | 4500 | ||
| Maximum pulse energy （J） | 30 | 45 | ||
| Pulse Width Range （ms) | 0.03-50 | |||
| Power Stability (%) | ±1 | |||
| Beam quality M² | 1.6 （50um） | 4（100um） | ||
| Spectral bandwidth (3dB)(nm) | 3-5 | |||
| polarisation state | stochastic | |||
| Power Adjustment Range (%) | 10-100 | |||
| Indicated red power (μW) | ≥200 | |||
| output method | QBH | |||
| Output Cable Length (m) | 10 （customisable） | |||
| Fibre optic cable bending radius (mm) | 200 | |||
| Output Fibre Core Diameter （μm） | 50(14/25/100/200) customisable | 100(34/50/100) customisable | ||
| Supply Voltage (VAC) | 380 | |||
| input power (KW) | 3 | 4 | ||
| Working environment temperature (℃ ) | 10-35 | |||
| Relative humidity of working environment (%) | 10-80 | |||
| storage temperature (℃ ) | -10-60 | |||
| Cooling method | Air-cooled | Air-cooled / Water-cooled | ||
| Dimension of the whole machine | 482.6*731*105 | 482.6*781*133 | ||
| Weight (kg) | 53 | 62 | ||
Get Free Quote of QCW 300W, 450W Laser Sources
QCW 300/450W Sample photos
